Controls for agitators
Contact us for more information
| Performance range | 4 unti 30kW (higher capacities on request) |
| Drive type | Electric motor |
| Connection | 3x400V~ (3L+N+PE oder 3L+PE) |
| Function | Control for agitator / Motor protection switch / Motor starter |
| Availability | from stock (Standard) / 2-4 days delivery time (Spezial) |
Whether submersible agitators, winged agitators, blade-type agitators, biogas agitators, propeller agitators or tractor mixers, our controls are adapted for every use and are available as star-delta, soft start or frequency converter controls.
The agitators controls are available in various standard versions. They have a standard wireless/distance connection so that the agitator can be switched on or off by wireless remote controls or by an external signal.
We offer the following standard versions:
- Star delta 5.5 – 30kW with wireless/distance connection
- Star-delta 5.5 – 30kW wih integrated timer
- Star-delta 5.5 – 30kW with integrated timer and/or hour counter
- Softstart 5.5 – 30kW with wireless/distance and timer connection
- Softstart 5.5 – 30kW with wireless/distance connection and timer
- Softstart 5.5 – 30kW with wireless/distance and timer connection including automatic turning function
- Softstart 5.5 – 30kW with wireless/distance and timer connection including manual turning function
- Softstart 5.5 – 30kW with wireless/distance and timer connection twofold for double agitator operation
- Frequency converter 5.5 – 30kW nominal voltage regulated for constant economical operation whether the slurry pit is full or empty
- Frequency converter 5.5 – 30kW nominal voltage regulated including automatic turning function
- Frequency converter 5.5 – 30kW nominal voltage regulated including manual turning function
- Frequency converter 5.5 – 30kW nominal voltage regulated including turning function with economy drive
We can implement further client wishes quickly, efficiently and cost-effectively.
- Option operational hours counter
- Option SPS with or without display for time settings/connections
- Option 3.5” touch display for setting parameters or as machine controls/emergency controls
- Option 7” touch display for setting parameters or as machine controls/emergency controls
- Option 12” touch display for setting parameters or as machine controls/emergency controls
- Option integrated CoDeSys SPS (programmable controller logic) according to IEC 61131-3 for special solutions
- Further options and wishes upon request
- Rapid and cost-effective special devices
- We optimise your control options and reduce your stock
